| Type |
Horizontal Triplex Single
Acting Piston Pump |
Gear Type |
Herringbone |
| Rated Power, HP (kW) |
1,600 (1,193) |
Gear Ratio |
4.206:1 |
| Rated Pump Speed, SPM |
120 |
Maximum Liner Size by Stroke Length, inches (mm) |
7" x 12" (178 x 305) |
| Suction Connection, inches (mm) |
12" (305) |
Valve Pot |
API # 7 |
| Discharge Connection |
5-1/8" ( 130 mm ) 5,000
psi (34.5 MPa) Flange |
Approximate Weight, lbs (kg) |
54,655 (24,791) |
|
|
Liner Size, inches (mm) |
7
(178) |
6-3/4
(171) |
6-1/2
(165) |
6
(152) |
5-1/2
(140) |
5
(127) |
Rated Pressure
psi (MPa) |
3,430
(23.6) |
3,690
(25.4) |
3,978
(27.4) |
4,668
(32.2) |
5,000
(34.5) |
5,000
(34.5) |
|
Pump Speed, SPM |
Input Power
HP (kW) |
Displacement, GPM (LPM ) |
|
120 |
1,600
(1,193) |
720
(2,725) |
669
(2,533) |
621
(2,351) |
529
(2,002) |
444
(1,681) |
367
(1,389) |
|
110 |
1,467
(1,094) |
660
(2,498) |
613
(2,320) |
569
(2,154) |
485
(1,836) |
407
(1,541) |
337
(1,276) |
|
100 |
1,334
(995) |
600
(2,271) |
558
(2,112) |
517
(1,957) |
441
(1,669) |
370
(1,400) |
306
(1,159) |
|
90 |
1,200
(895) |
540
(2,044) |
502
(1,900) |
465
(1,760) |
397
(1,503) |
333
(1,261) |
275
(1,041) |
|
80 |
1,067
(796) |
480
(1,817) |
446
(1,688) |
414
(1,567) |
353
(1,336) |
296
(1,120) |
245
(928) |
70 |
933
(696) |
420
(1,590) |
390
(1,477) |
362
(1,370) |
308
(1,166) |
259
(980) |
214
(810) |
|
Volume/Stroke, gallons (liters) |
6.00
(22.71) |
5.58
(21.12) |
5.17
(19.57) |
4.41
(16.69) |
3.70
(14.00) |
3.06
(11.59) |
|
